20K758USB-SYS-1/21K758USB-SYS-1
Videology Driver Download For Windows 10 Pro
- CCD sensor provides high sensitivity and quality
- Still image capture with streaming video
- Flexible gooseneck arm allows for easy camera control
- Small footprint saves table space
- Megapixel options are available
- USB 2.0 bus provides power and camera control
- Complete SDK available
Software
Install chicony usb 2.0 camera driver for windows 10 x64, or download driverpack solution software for automatic driver installation and update. 0 pc camera processor family are 6. Free shipping on the solaris usb 2. USB, Everything You Need to Know. For a scanner, or windows 7 32 bit. Download the file to a folder on your hard drive, and then run (double-click) it to unzip the set of files. Follow the instructions to complete the installation. It is highly recommended to always use the most recent driver version available. Videology Imaging Systems Linux drivers support Ubuntu Linux versions 2.6.31 through 2.6.39. We are developing and testing versions 3.0 and later ON AN AS- NEEDED BASIS BY OEM PRIORITIZATION. For other derivatives of the Linux operating systems in particular Red Hat, Debian, Fedora, we will be developing those versions of the driver later. We have released a compatible version of EPI Suite for Windows 7, 8, 8.1 (64-bit only) and 10 (64-bit only) operating systems to our Channel Partners. This version is compatible on both 32-bit and 64-bit systems. Please contact your vendor for further information.
Videology Driver Download For Windows 10 32-bit
- USB 2.0 viewer software and Microsoft Digitally Certified WDM Device Drivers for 32bit and 64bit Windows operating systems
- DirectX/DirectShow compliant
- TWAIN compliant
- Select Linux driver available
| Electrical | ||
|---|---|---|
| Image Sensor | 1/3' | |
| Active Pixels (HxV) | 768 x 494 (NTSC) 752 x 582 (PAL) | |
| Viewer Display | (USB 2.0, 30fps) | 720 x 480 pixels max (NTSC) 720 x 576 pixels max (PAL) |
| Sensitivity | < 0.5 Lux | |
| Signal To Noise Ratio | > 48 dB (AGC off) | |
| Gamma | 0.45 default (1.0 via Software) | |
| Gain Control | Automatic 36 dB (AGC default) or Fixed options via software | |
| Scan Mode | Interlaced | Non Interlaced (selectable via Software) | |
| Mirror Mode | Yes (horizontal/vertical) | |
| Synchronization | Internal | |
| Back Light Compensation | Default on (selectable via software) | |
| White Balance Mode | AWB auto white mode, Fixed modes selectable via software | |
| Contour Enhancement | Default on | |
| Iris Control | CCD Iris default | |
| Shutter Speeds | Automatic | |
| 14 fixed speeds via software 1/7.5 - 1/100,000 (NTSC) 1/6.5 - 1/100,000 (PAL) | ||
| Control Communication | Camera control via USB bus | |
| Video Output | USB 2.0 | |
| Power Supply | 5VDC via USB bus | |
| Power Consumption | < 1.3 W | |
| Environmental | ||
| Operating Temperature | -15°C to + 55°C (5°F to + 131°F) | |
| Operating Humidity | 20% up to 93% RH | |
| Storage Temperature | -25°C to + 70°C (-13°F to + 158°F) | |
| Storage Humidity | Up to 98% RH | |
| Mechanical | ||
| Dimensions WxHxD | 13.2cm x 52cm x 12cm (5.2' x 20.6' x 4.7') (from center of camera to bottom of base) | |
| Weight | 2.1kg (4.8 lbs) | |
| Included Cable | Integrated 8.2ft. USB 2.0 cable | |
| Included Lens | Fixed 8mm f1.8 CS lens (30S0818L) | |
| Safety Standards | RoHS | |
| Viewer (included) SFT-07019 |
| |
| SDK (optional) SFT-07019-SDK | Complete software development kit and support for OEMs | |
| Minimum System Requirements | Hardware | Pentium IV 2.3GHz +, 1GB hard drive, Intel USB 2.0 Host controller |
| Software | Windows 7, 8, 10 32 bit and 64 bit | |
| Windows Vista 32 bit and 64 bit | ||
| Windows XP Service pack 2 +, DirectX 9.0c or above | ||
| Software Downloads | ||
|---|---|---|
| SFT-07019 rev 1.0.160 | Latest USB 2.0 viewer software and drivers for 32bit and 64bit Windows operating systems (not Microsoft Digitally Certified) | |
| SFT-07019-WHQL rev 1.0.129S | Microsoft Certified USB 2.0 viewer software USB 2.0 viewer software and Microsoft Digitally Certified WDM Device Drivers for 32bit and 64bit Windows operating systems. | |
| SFT-10011 rev 2.1.25 | TWAIN Data Source for Videology USB Cypress cameras. | |
| SFT-15002 rev 77 | .NET Wrapper DEMO software | |
Videology Driver Download For Windows 10 7
| 24C7.38USB | USB, High Resolution Color Camera for Photo Identity Systems |
